LÖWE Mobile Scissor Lift Platform – 6–13.7 m – Fully Electric – Profi SABE Series

€11.852,00

Mobile Electric Scissor Lift Platforms – LÖWE Profi SABE6.0 / SABE8.0 / SABE10.0 / SABE11.8 / SABE13.7

The LÖWE Profi SABE series consists of fully electric scissor lift platforms designed for demanding work at height where precision, safety and maximum flexibility are required.

Thanks to the fully electric drive system, the platforms can both lift and travel electrically without the use of combustion engines. This makes them particularly quiet and emission-free, making the machines well suited for indoor applications and sensitive working environments.

The series is available in five configurations with platform heights ranging from 6.0 m to 13.7 m and maximum working heights of up to 15.7 m.

Key Features

Fully electric lifting and travel drive
Electric lifting and driving allow convenient positioning of the platform, including when the platform is raised.
Emission-free and low-noise operation
Particularly suitable for indoor environments, warehouses, shopping centers, exhibition halls and other noise-sensitive areas.
Compact design and high maneuverability
A small turning radius enables precise maneuvering in confined work areas.
Powerful battery system
Reliable energy supply for extended operating periods with efficient and low-maintenance operation.
Smooth and stable lifting
A precision scissor mechanism and high-quality hydraulic components provide controlled and consistent platform movement.
Comprehensive safety features
Equipment includes overload protection, inclination sensors, emergency lowering and low-voltage control technology.
Spacious working platform
Provides room for operators, tools and materials, with an optional platform extension for additional reach.
Non-marking tires
Designed for use on sensitive flooring and indoor surfaces.
Robust and durable construction
High-quality steel frame construction with a durable powder-coated finish for long service life.

Typical Applications

The LÖWE Profi SABE series is particularly suitable for environments requiring clean, quiet and precise operation.

Industrial and Production Facilities

Maintenance, assembly and servicing work on machinery, equipment and production lines.

Warehouses and Logistics Centers

Order picking, rack maintenance, lighting work and installation tasks in indoor facilities.

Building Services and Facility Management

Work on ceilings, ventilation, air-conditioning and electrical installations in commercial and public buildings.

Exhibition, Event and Hall Construction

Installation of lighting, banners, trusses and decorative elements for events and exhibitions.

Shopping Centers and Public Facilities

Suitable for sensitive indoor environments thanks to emission-free operation and non-marking tires.

Workshops and Service Facilities

Maintenance and repair work in confined or difficult-to-access areas.

Indoor Areas with High Safety Requirements

Suitable for environments where exhaust gases, excessive noise or open flames are not permitted.

Technical Specifications

Profi SABE6.0

Specification	Value
Maximum platform height	6.0 m
Maximum working height	8.0 m
Rated load capacity	500 kg
Platform extension load capacity	113 kg
Platform dimensions (L × W × H)	2.27 × 1.12 × 1.13 m
Overall dimensions, guardrails raised (L × W × H)	2.43 × 1.22 × 2.28 m
Overall dimensions, guardrails folded (L × W × H)	2.43 × 1.22 × 1.71 m
Platform extension	0.9 m
Ground clearance	0.10 / 0.02 m
Wheelbase	1.89 m
Turning radius, inner / outer	0.4 / 2.4 m
Lift / drive motor	24 V / 3.3 kW
Lifting speed	6–9 m/min
Travel speed, lowered	3.5 km/h
Travel speed, raised	0.8 km/h
Battery	4 × 6 V / 200 Ah
Charger	24 V / 30 A
Gradeability	25%
Maximum working inclination	1.5° / 3°
Tires	Ø 381 × 127 mm
Tire type	Non-marking solid tires
Total weight	2,150 kg

Profi SABE8.0

Specification	Value
Maximum platform height	8.0 m
Maximum working height	10.0 m
Rated load capacity	450 kg
Platform extension load capacity	113 kg
Platform dimensions (L × W × H)	2.27 × 1.12 × 1.10 m
Overall dimensions, guardrails raised (L × W × H)	2.469 × 1.20 × 2.344 m
Overall dimensions, guardrails folded (L × W × H)	2.469 × 1.182 × 1.843 m
Platform extension	0.9 m
Ground clearance	0.10 / 0.02 m
Wheelbase	1.89 m
Turning radius, inner / outer	0 / 1.7 m
Lift / drive motor	24 V / 3.3 kW
Lifting speed	3–5 m/min
Travel speed, lowered	3.5 km/h
Travel speed, raised	0.8 km/h
Battery	4 × 12 V / 103 Ah
Charger	24 V / 30 A
Gradeability	25%
Maximum working inclination	1.5° / 3°
Tires	Ø 381 × 127 mm
Tire type	Non-marking solid tires
Total weight	2,150 kg

Profi SABE10.0

Specification	Value
Maximum platform height	10.0 m
Maximum working height	12.0 m
Rated load capacity	320 kg
Platform extension load capacity	113 kg
Platform dimensions (L × W × H)	2.27 × 1.12 × 1.10 m
Overall dimensions, guardrails raised (L × W × H)	2.43 × 1.20 × 2.55 m
Overall dimensions, guardrails folded (L × W × H)	2.43 × 1.22 × 1.97 m
Platform extension	0.9 m
Ground clearance	0.10 / 0.02 m
Wheelbase	1.89 m
Turning radius, inner / outer	0 / 1.7 m
Lift / drive motor	24 V / 3.3 kW
Lifting speed	6–9 m/min
Travel speed, lowered	3.8 km/h
Travel speed, raised	0.8 km/h
Battery	4 × 12 V / 103 Ah
Charger	24 V / 30 A
Gradeability	25%
Maximum working inclination	1.5° / 3°
Tires	Ø 381 × 127 mm
Tire type	Non-marking solid tires
Total weight	2,500 kg

Profi SABE11.8

Specification	Value
Maximum platform height	11.8 m
Maximum working height	13.8 m
Rated load capacity	320 kg
Platform extension load capacity	100 kg
Platform dimensions (L × W × H)	2.27 × 1.12 × 1.13 m
Overall dimensions, guardrails raised (L × W × H)	2.43 × 1.22 × 2.67 m
Overall dimensions, guardrails folded (L × W × H)	2.43 × 1.22 × 2.09 m
Platform extension	0.9 m
Ground clearance	0.10 / 0.02 m
Wheelbase	1.89 m
Turning radius, inner / outer	0.4 / 2.4 m
Lift / drive motor	24 V / 4.5 kW
Lifting speed	6–9 m/min
Travel speed, lowered	2.7 km/h
Travel speed, raised	0.8 km/h
Battery	4 × 6 V / 200 Ah
Charger	24 V / 30 A
Gradeability	25%
Maximum working inclination	1.5° / 3°
Tires	Ø 381 × 127 mm
Tire type	Non-marking solid tires
Total weight	2,600 kg

Profi SABE13.7

Specification	Value
Maximum platform height	13.7 m
Maximum working height	15.7 m
Rated load capacity	227 kg
Platform extension load capacity	113 kg
Platform dimensions (L × W × H)	2.64 × 1.12 × 1.13 m
Overall dimensions, guardrails raised (L × W × H)	2.80 × 1.39 × 2.66 m
Overall dimensions, guardrails folded (L × W × H)	2.80 × 1.39 × 2.09 m
Platform extension	0.9 m
Ground clearance	0.10 / 0.02 m
Wheelbase	2.26 m
Turning radius, inner / outer	0.45 / 2.9 m
Lift / drive motor	24 V / 4.5 kW
Lifting speed	6–9 m/min
Travel speed, lowered	2.7 km/h
Travel speed, raised	0.8 km/h
Battery	Maintenance-free lead-acid battery
Charger	24 V / 30 A
Gradeability	25%
Maximum working inclination	1.5° / 3°
Tires	Ø 381 × 127 mm
Tire type	Non-marking solid tires
Total weight	3,210 kg

Model Comparison

Specification	Profi SABE6.0	Profi SABE8.0	Profi SABE10.0	Profi SABE11.8	Profi SABE13.7
Maximum platform height	6.0 m	8.0 m	10.0 m	11.8 m	13.7 m
Maximum working height	8.0 m	10.0 m	12.0 m	13.8 m	15.7 m
Load capacity	500 kg	450 kg	320 kg	320 kg	227 kg
Platform extension load capacity	113 kg	113 kg	113 kg	100 kg	113 kg
Platform extension	0.9 m	0.9 m	0.9 m	0.9 m	0.9 m
Total weight	2,150 kg	2,150 kg	2,500 kg	2,600 kg	3,210 kg
Lift / drive motor	24 V / 3.3 kW	24 V / 3.3 kW	24 V / 3.3 kW	24 V / 4.5 kW	24 V / 4.5 kW
Travel speed, lowered	3.5 km/h	3.5 km/h	3.8 km/h	2.7 km/h	2.7 km/h
Travel speed, raised	0.8 km/h	0.8 km/h	0.8 km/h	0.8 km/h	0.8 km/h
Gradeability	25%	25%	25%	25%	25%
Maximum working inclination	1.5° / 3°	1.5° / 3°	1.5° / 3°	1.5° / 3°	1.5° / 3°
Tire type	Non-marking solid	Non-marking solid	Non-marking solid	Non-marking solid	Non-marking solid
